King Midas JL855 Vertical Machining Center

Product details

model	JL-855
Workbench size (mm)	1,000*550
Processing area (mm)	850*550
Three axis travel X/Y/Z (mm)	850550550
Three axis servo motor (Mitsubishi) (kw)	1.5/1.5/3.0
Three axis servo motor (Fanuc) (kw)	1.8/1.8/3.0
Three axis cutting feed（X/Y/Z Axis） (mm/min)	1-10,000
Three axis rapid displacement（X/Y/Z Axis） (m/min)	48/48/48
Rail specifications (X/Y/Z Axis)	45/45/45(Roller)

1. The quality testing of Jinmei Machinery includes:

-Semi complete three-axis accuracy check

-Complete a 48 hour half-hour test

-Complete 3-axis accuracy check

-Complete a 48 hour test run

-100% inspection completed

2. Ultra wide base - The base of the Jinde JL series is wider than the stroke, and the column design has a revolutionary feature, allowing the machine to achieve perfect triangular balance in mechanical structure, thereby achieving ideal stability and stiffness. Ensure stable performance of the machine in parts production and mold production.

In larger JL series machines, we are equipped with 4 linear roller type linear guides, providing a smoother and more reliable performance foundation for the machine. It can be interchanged between BT40 and BT50 to meet customer needs.
